Product Details
technical parameter
Optional character dot matrix
Single line: 5x5 7x5 9x7 12x9 16x14 24x22 32x30
Double line: 5x5 7x5 9x7 12x9 16x14
Three lines: 5x5 7x5 9x7
Four lines: 5x5 7x5
Five elements: 5x5
Number of lines / height / speed / distance
Maximum number of lines printed: 5 lines
Character height: 1-15mm
Maximum printing speed: 406 m / min
Best printing distance: 10mm from the surface
Nozzle size
Nozzle: 40 micron (micro type machine) 50/56/60/70/75 micron
Standard characteristics
Print Delay, Auto Reset, Auto Invert Flip, Print Count, User Time Format, Adjustable Character Height and Width, Serial Number Print, Flip, Reverse, Bold Character, Information Repeat Bar Code, QR Code Print, External Counter Reset Switch, standard speed and high speed selection, two sets of fonts to choose from.
Ink system
Ink viscosity control: automatic
Ink emptying control: automatic operation at boot
Ink and diluent addition: 600ML or 825ML box, automatically added
data input
Rs232 USB port data export / import
surroundings
Temperature range: 5 ° C - 15 ° C operating conditions
Humidity: 10%-90% (no frosting)
Power: 200-240VAC 50/60Hz 120W
Chassis
Surface treatment: 304 stainless steel
Protection level: IPS (1997)
Pipe length: 3 meters or 6 meters
Chassis size: 446x221x647mm
Optional accessories: alarm light, light eye, base. Encoders, etc.
